Honeywell TS8205A User Manual

T8205B,C, TS8205B,C ELECTRONIC POOL, SPA CONTROL SYSTEMS;
T8205A,H, TS8205A CONTROL MODULES; Q8205A-C SETPOINT PANELS AND SENSOR ASSEMBLY
68-0177—1
7
Fig. 6. TS8205B,C wiring connections for high limit control (TS8205B shown).
Fig. 7. T8205H wiring connections for heat pump heating
applications.
SENSOR
M11016B
TS8205A
TS8205B
Q8205B
POLARITY IS CRITICAL. FOLLOW POLARITY MARKINGS WHEN WIRING. FAILURE TO
DO SO RESULTS IN MALFUNCTION.
LIMIT ACTION WITH HIGH LIMIT WIRED BETWEEN GAS CONTROL AND GENERATOR LOCKS OUT
HEATER UNTIL PILOT IS MANUALLY RELIT. ALTERNATE HIGH LIMIT LOCATION ALLOWS AUTOMATIC
HEATER RESTART AFTER LIMIT SWITCH REMAKES.
FACTORY WIRED ON TS8205B,C.
1
2
2
SEN
SEN
POT
POT
-(TH/PP)
+(PP)
VALVE
(TH)
ALTERNATE
HIGH LIMIT CONTROL
LOCATION (AUTO RECYCLE)
TH
TH
PP
PP
HIGH LIMIT
CONTROL
(MANUAL
RELIGHT)
Q313
POWERPILE
MILLIVOLT
GENERATOR
_
+
®
SWITCH
POT
1
2
3
3
Fig. 8. T8205H wiring connections for heat pump cooling
applications.
SETTINGS
Select Control Temperature
The control temperature is set by turning the setpoint
potentiometer. The limit of clockwise rotation with the shaft
toward you represents the maximum 106°F (41°C) setting.
Turning the potentiometer counterclockwise through its full
rotation moves the setting to the minimum limit. On models
with two potentiometers, one potentiometer is used to set the
pool temperature, and the other is used to set the spa
temperature. See Fig. 9 for a setting guide.
CHECKOUT
Check out the system by observing it through at least one
complete cycle, making sure it operates as desired. Check
the sensor by comparing its resistance to the temperature as
measured by an accurate thermometer. The resistance of the
sensor increases as its temperature drops. The
troubleshooting chart, Fig. 10, shows the relationship
between sensor resistance and temperature.
POT 1
POT 2
C
N.O.
SEN SEN N.C.
L2
L1
(HOT)
SENSOR
FUSE
LIMIT(S)
24 VAC
24 VAC
HOT
24 VAC
COM
POT
M15513
T8205H
CONTACTOR
POT 1
POT 2
C
SEN SEN N.C.
L2
L1
(HOT)
SENSOR
FUSE
LIMIT(S)
24 VAC
POT
M15514
T8205H
CONTACTOR
N.O.
24 VAC
HOT
24 VAC
COM
