SPECIFICATIONS • ORDERING INFORMATION
Specifications
MODELS:
V5055A Industrial Gas Valve for On-Off service.
V5055B Industrial Gas Valve with characterized guide for
slow opening, HI-LO-OFF, or modulating service. V5055C:
Same as V5055A but incorporates a double seal. Used with
the V4055D Actuator to a provide proof-of-closure switch
and a valve seal overtravel
interlock.
V5055D: Same as V5055A but for high pressure appli-
cations.
V5055E: Same as V5055C but for high pressure appli-
cations.
TYPE OF GAS: Natural or liquefied petroleum (LP) only. PIPE
SIZE: 3/4, 1, 1-1/4, 1-1/2, 2, 2-1/2, 3, and 4 in. (only
V5055A,B,C available in 4 in. size).
PIPE THREADS: NPT or BSP-PL Threads (equivalent to ISO
R7 and DIN 2999). Available on inlet and outlet of 3/4 to 3
inch valves. Four inch valves have flange connec- tions.
PRESSURE RATINGS: See Table 1. VALVE
BODY RATING: 75 psi (517.1 kPa).
VALVE CAPACITIES: A.G.A. ratings at 1 in. (0.25 kPa)
pressure drop; based on gas with specific gravity of 0.64.
TABLE 1—PRESSURE RATINGS OF VALVE-ACTUATOR COMBINATIONS.
Valve
Actuator
V4055A,D
c
V4055B,E
c
V4062,V9055
c
psi
kPa
psi
kPa
psi
kPa
psi
kPa
psi
kPa
psi
kPa
V5055A,C
3/4 to 3 in.
5
34.5
15
103.4
15
103.4
15
103.4
5
34.5
14
103.4
V5055A,C
4 in.
3
20.7
15
103.4
5
34.5
15
103.4
3
20.7
15
103.4
V4055B
3/4 to 3 in.
5
34.5
15
103.4
15
103.4
15
103.4
5
34.5
15
103.4
V5055B
4 in.
3
20.7
15
103.4
5
34.5
15
103.4
3
20.7
15
103.4
V5055D,E
3/4, 1, 1-1/4, 1-1/2 in.
5
34.5
75
517.1
25
172.4
75
517.1
5
34.5
75
517.1
V5055D,E
2, 2-1/2, 3 in.
5
34.5
45
310.3
15
103.4
45
310.3
5
34.5
45
310.3
a
Maximum operating pressure differential.
b
Maximum close-off pressure without seal leakage. This is the maximum allowable pressure drop to which a valve may be
subjected while fully closed, and is independent of the valve body rating.
c
Use a V4055D, V4055E, V4062D, or V9055D (with proof-of-closure switch) with a V5055C or E (with double seal) for valve
seal overtravel interlock.
Ordering Information
When purchasing replacement and modernization products from your TRADELINE
®
wholesaler or distributor, refer to the TRADELINE
®
Catalog or price
sheets for complete ordering number, or specify—
1. Order number
2. Pipe size.
3. NPT or parallel BSP threads (except for 4 in. models with flanges).
4. Optional additional tapping and plug—1/8 in downstream and/or 1/2 in. upstream.
5. Replacement parts, if desired.
