REPLACEMENT PARTS AND ACCESSORIES
Contents
Replacement parts and accessories page
Flange assemblies..........................................................32
Fitting ............................................................................32
Gas pressure switch .....................................................33
Miscellaneous ...............................................................33
Plugs ..............................................................................33
FLANGE ASSEMBLIES
1)
Not applicable for mounting over pilot outlet.
2)
Applicable for mounting in all directions.
* Provided with
1
/
8
” BSP. Tr pressure tap hole
FITTING
1)
Only applicable for VK41../VK81..R
Connection size Configuration ”O”-ring and
screws
Packing quantity
(pcs)
Order number
Straight Elbow
3
/
8
” BSP.Pl X - YES 200 45.900.400-101
3
/
8
” BSP.Pl
1)
- X YES 200 45.900.400-103
3
/
8
” BSP.Pl
1)
- X Only “O”-ring 200 45.900.400-129
1
/
2
” BSP.Pl X - YES 200 45.900.400-102
1
/
2
” BSP.Pl X - NO 200 45.900.400-106
1
/
2
” BSP.Pl X - Only “O”-ring 200 45.900.400-131
1
/
2
” BSP.Pl X - YES 10 45.002.776-041
1
/
2
” BSP.Pl
1)
- X YES 200 45.900.400-104
1
/
2
” BSP.Pl
1)
-X* NO 200 45.900.400-108
1
/
2
” BSP.Pl
1)
-X* Only “O”-ring 200 45.900.400-130
1
/
2
” BSP.Pl
1)
X - YES 10 45.002.776-042
1
/
2
” NPT X - YES 200 45.900.400-122
3
/
4
” NPT
1)
- X YES 200 45.900.400-146
Ø 18.4 mm X - YES 200 45.900.400-123
Description Material Packing quantity Ordernumber
Compression fitting M8 x 1 for 4 mm pilot tube connection Brass 200 45.900.402-019
Compression fitting M10 x 1 for 6 mm pilot tube connection
1)
Brass 200 45.900.402-020
Compression fitting M11 x 1 for 6 mm pilot tube connection
1)
Brass 200 45.900.402-002
Pressure feedback fitting for 4 mm tube Brass 200 45.900.402-010
Pressure feedback fitting for 6 mm tube Brass 200 45.900.402-011
Pressure feedback fitting for 4 mm tube Polyamide 6.6 100 45.900.402-031
Pressure feedback fitting for 6 mm tube Polyamide 6.6 100 45.900.402-034
