Honeywell XNX-UTAE Series User Manual

XNX Universal Transmitter
Index
201
A
accessories 158
air speed, operating 133
alarm/fault simulation 86
alarm/fault status 88
alarms 72
alarm settings 88
approvals,
hazardous area 132
performance 132
B
battery life 131
baud rate 185
beam block options 78
bump test See functional
gas test
C
cable
length 56
ports 131
recommended 131
cal gas range 136, 137
Calibration 94–108
calibration
for MPD sensors 61, 102
gas 95
gas ow adapter 17
interval 76
span 95, 96
zero 95, 96
cal point 135, 136, 137
cartridges
catalytic bead replace-
ment 157
IR replacement 157
part numbers 135, 136,
137
Cautions 7
ceiling mount bracket kit
18, 158
cells, replacement 156
certications 31, 72
by part number series
148–151
chronological list, event,
by day 93
collecting cone 18, 159
Communications 12
conguration
displaying 24
verifying 84
congure menu 62
construction material 131
Control Drawings 163–170
remote sensor mount
170
UL/CSA/FM 167-169
UL/INMETRO 164-166
controls 20
cover 15
cross-interferents 145
D
daisy-chain 34
date 63, 88
dimensions 131
duct mount kit 19, 158
E
easy reset 83
EC See electrochemical
sensor
electrochemical sensor 43
cartridge, replacing with
different type 106
cartridge, replacing with
same type 105
cell 111
installation 43
operational life 105
enclosure
aluminum 14
stainless steel 14
event history 88, 92
Excel, aligning 107
F
eldbus
options 82
settings 88, 91
nish, marine 14
ow housing 103
force relays 88, 86
FOUNDATION Fieldbus 59
front panel 19
functional gas test 24,
105, 106
G
gas calibration 24, 95
gas data 88, 90
gases, selectable 66
gas name, changing 67
general status screen 21,
60
greases, airborne 145
H
H
2
S sensors, calibrating
99
HART
devices 56
handheld online menu
182–183
interface 172–174
local 16
local handheld 172-178,
182-183
output 12
protocol 55, 172–184
hex key 15
humidity 131, 135, 136,
137
hydrogen sensors 146
I
information 9
information menu 88
inhibit 84
Installation and Operation
29–93
installation
daisy-chain 34
maximum distance 36
multiple transmitter 34
single transmitter 34
types of 34
intrinsic safety 6, 16, 33
Introduction 10–28
IP rating 131
IS See intrinsic safety
