XNX Universal Transmitter
Installation and Operation
97
Event History
The Event History screen lists all events that are activated by the transmitter’s settings. Five types of events are recorded: reset
messages, alarm messages, warning messages, fault messages, and informational messages. The events are listed in chronological
order beginning with the latest.
Events can be displayed through ve browsing modes:
• all events in order of occurrence
• all events by hour
• all events by day
• only the alarm events, in order of occurrence
• only the fault events, in order of occurrence
The Event History screen groups events into chronological order (beginning from the unit’s installation). Events can also be viewed
by hour or by date.
Events listed in
hour
order are grouped without regard to date. For example, all events that have occurred between noon and 1:00
o’clock since the transmitter’s installation can be isolated. To view all events in hour order:
1. Use the magnetic wand to lter the display by hour.
2. Navigate through the displayed times.
To isolate all of the events from a specic
day
:
1. Use the magnetic wand to lter the display by day.
2. Navigate through the displayed days.
3. Filter the list by all events. This will display all events that occurred on that day.
When the transmitter is congured with the Searchline Excel or Searchpoint Optima, the data reported in the event will be the fault
code from the Searchline Excel or Searchpoint Optima.
The transmitter records up to 1280 events in a circular buffer. When event 1281 is recorded, the oldest event will be deleted from the
list.
