Hoover UH71250 User Manual

POSITION TOOLS
1. VACUUM ASSEMBLY
A. Handle*
B. Vacuum Base
C. Wand
D. Crevice Tool
E. Turbo Tool
F. Adjustable Dusting Brush*
G. (1) Large Screw
H. Dirt Cup
*Varies per model.
Remove all parts from carton and identify
each item shown.
Make sure all parts are located before
disposing of packing materials.
5
1.2 1.3
1.2 Insert handle section into vacuum base. Push
down firmly. Using a Phillips screwdriver, fasten (1) large
screw behind handle into vacuum base.
1.3 Wrap hose around top of hose guide located on the
handle. Insert the hose into hose tube until you hear a click.
ATTACH DIRT CUP
1.6
1.6 Place bottom of dirt cup into vacuum body first.
Pivot cup into vacuum. Dirt cup is secure when you hear a
click.
1.4 Place Crevice Tool into Wand and slide into tool storage
area on left back side (C) of vacuum and place Turbo Tool on
right back side (E) of vacuum as shown.
1.5 Place adjustable dusting brush (F) on top of wand.
CARTON CONTENTS
1.1
A
Actual model may vary from images shown.
ATTACH HANDLE
B C
G
H
E FD
1.5
E
F
C
1.4

Hoover UH71250 Specifications

General

Style	upright vacuums
Color	cobalt blue & iron ore, blue
Floor Type	all floors
Dust Bin Capacity	1.29 gallons
Cord Length	25 feet
Carpet Height Adjustments	yes
Automatic Cord Rewind	yes
Filter	hepa, allergen, 2-stage, reusable
Washable Filter	yes
Pet Mode	yes
Hypoallergenic	no
Brush Roll Shut-Off	no
Bagless	no
?leaning Area	13.5 inches
Brushes and Accessories	crevice tool; pet turbo tool; pivoting dusting tool
Voltage	120 volts
Current	12 amperes

Weight and Dimensions

Length	13 inches
Height	44.5 inches
Width	13.5 inches
Net Weight	21.7 pounds
