POSITION TOOLS
1. VACUUM ASSEMBLY
A. Handle*
B. Vacuum Base
C. Wand
D. Crevice Tool
E. Turbo Tool
F. Adjustable Dusting Brush*
G. (1) Large Screw
H. Dirt Cup
*Varies per model.
Remove all parts from carton and identify
each item shown.
Make sure all parts are located before
disposing of packing materials.
5
1.2 1.3
1.2 Insert handle section into vacuum base. Push
down firmly. Using a Phillips screwdriver, fasten (1) large
screw behind handle into vacuum base.
1.3 Wrap hose around top of hose guide located on the
handle. Insert the hose into hose tube until you hear a click.
ATTACH DIRT CUP
1.6
1.6 Place bottom of dirt cup into vacuum body first.
Pivot cup into vacuum. Dirt cup is secure when you hear a
click.
1.4 Place Crevice Tool into Wand and slide into tool storage
area on left back side (C) of vacuum and place Turbo Tool on
right back side (E) of vacuum as shown.
1.5 Place adjustable dusting brush (F) on top of wand.
CARTON CONTENTS
1.1
A
Actual model may vary from images shown.
ATTACH HANDLE
B C
G
H
E FD
1.5
E
F
C
1.4
To Next Page
