Horizon Hobby Blade mCP X BL 2 User Manual

Components
Airframe
Blade mCP X BL Included
Motors
Brushless (BLH6003, BLH6004) Installed
Flybarless Unit
3-in-1 Control Unit with SAFE
®
technology (BLH6001) Installed
Battery
280mAh 2S 3.7V 30C Li-Po Battery Required
Charger
2S Li-Po Charger Required
Transmitter
DSM2
®
/DSMX
®
Compatible Transmitter Required
EN
3
Length
275mm
Height
100mm
Flying Weight
62g
Main Rotor Diameter
263mm
Tail Rotor Diameter
40mm
Specifi cations
Table of Contents
Transmitter Setup Table .......................................4
Installing the Flight Battery ..................................6
Transmitter and Receiver Binding ......................... 6
Control Tests .......................................................7
Understanding the Primary Flight Controls ............ 8
Flight Modes ....................................................... 9
Panic Recovery ...................................................9
First Flight Preparation ......................................10
Flying Checklist ................................................. 10
Flying the mCP X BL 2 .......................................10
Drift Calibration ................................................. 11
Troubleshooting Guide .......................................11
Exploded View...................................................13
Replacement Parts ............................................ 14
Recommended Parts ......................................... 14
Optional Parts ...................................................14
Limited Warranty ............................................... 14
Warranty and Service Contact Information .......... 16
FCC Information ................................................16
IC Information ................................................... 17
Compliance Information for the European Union .... 17

Horizon Hobby Blade mCP X BL 2 Specifications

General

Brand	Horizon Hobby
Model	Blade mCP X BL 2
Category	Toy
Language	English
