EN
24
Problem Possible Cause Solution
Control surface does not
move
Control surface, control horn, linkage or servo
damage
Replace or repair damaged parts and adjust controls
Wire damaged or connections loose
Do a check of wires and connections, connect or
replace as needed
Transmitter is not bound correctly or the incorrect model was selected Re-bind or select correct model in transmitter
Flight battery charge is low Fully recharge flight battery
BEC (Battery Elimination Circuit) of the ESC is
damaged
Replace ESC
Controls reversed
Transmitter settings are reversed
Perform the Control Direction Test and adjust the
controls on transmitter
appropriately
Motor power pulses then
motor loses power
ESC uses default soft Low Voltage Cutoff (LVC)
Recharge flight battery or replace battery that is no
longer performing
Weather conditions might be too cold Postpone flight until weather is warmer
Battery is old, worn out, or damaged Replace battery
Battery C rating might be too small Use recommended battery
Aircraft control surfaces do
not move after switch is
turned on
Aircraft was moving during initialization Keep aircraft still during initialization
Hardware
Replacement Parts
Recommended Parts
Optional Parts
Part # Description
EFLA1030FB 30-Amp Telemetry Capable ESC
HBZ3101 Wing Set
HBZ3102 Fuselage
HBZ3103 Tail Set
HBZ3104 Cowl
HBZ3105 Pushrod Set
HBZ3106 Nose Gear
HBZ3107 Main Landing Gear
HBZ3108 Firewall and Motor Mount
HBZ3109 Nose Gear Arm and Mounting Strap
HBZ3110 Battery Door
HBZ3111 Wheels; 58mm (3)
HBZ3114 Spinner; 34mm
HBZ3115 Hardware Set
HBZ3116 Prop Adapter
HBZ3118 Decal Sheet
SPMAR631 AR631 6CH AS3X/SAFE Receiver
SPMR1010 DXS Transmitter Only
SPMSA381 9g Sub-Micro Servo: 400mm Lead
SPMSA382 14g Sub-Micro MG Servo, 240mm Lead
SPMX13003S30M 1300mAh 3S 11.1V Smart 30C LiPo;IC3
SPMXAM1900 2832-1300kv 14-pole
SPMXC1020 Smart S120 USB-C Charger, 1x20W
Part # Description
HBZ3113 Float Mounting Wires: MiniApprentice
HBZ7390 Float Set
SPMR6775 NX6 6 Ch Transmitter Only
RFL1205 RealFlight Trainer Edition RC Flight Simulator
SPMWS2000 WS2000 Wireless Simulator USB Dongle
SPMXPSA3 Smart Powerstage Aircraft 3S Bundle
SPMXC1070 Smart S150 AC/DC Charger, 1x50W
SPMXBC100 Smart Battery & Servo Tester
SPMXC2050 S155 G2 1x55W AC Smart Charger
Part # Description
SPMXPSA200 Smart G2 Air Powerstage 2
Location Description Quantity
Spinner M2.5 x 5mm Machine Screw 1
Cowl M2 x 4mm Self Tapping 3
Motor Mount M3 x 8mm Self Tapping 4
Motor M3 x 6mm Machine Screw 4
Nose Gear Strap M2.5 x 8mm Self Tapping 4
Nose Gear Set Screw M3 x 6mm Machine Screw 1
Landing Gear Strap M2.5 x 8mm Self Tapping 8
Wheel Collar M2.5 x 4mm Machine Screw 3
Vertical Stabilizer M2.5 x 8mm Self Tapping 2
Control Horns M2 x 8mm Machine Screw 8
To Next Page
