HOS Orbot - Storage

7
Fig. 20 Fig. 21
 • NOTE:Themachinebaseshouldnowrestontheblackbumperfoot,locatedatthebackofthe
bumper.Toavoiddamagetothehandleframe,DONOTlaythemachineframeontheoorasdone
withothertraditionalcleaningequipment.
 • Removethepadfromthedriverplatebypullingitdownrmly.ToremovetheHOSbrush,seep.9.
 • Putthemachineframeinanuprightpositionbypullingtheblackknobwiththelefthandandmove
thehandleframeupwardswiththerighthand.Theblackknobshouldlockrmlyinthetophole.
 • IMPORTANTSAFETYADVICE:Alwaysremovethepowercordfromtheelectricaloutletbefore
disconnecting it from the machine!
 • Toallowaneasytransportationofthemachine,removethewaterbottleandtheweightkitifused.
 • Toeasilyrollthemachine,createaleverageeffectbypushingyourfootonthebackwheelaxle
and pull the handle towards your body. The ORBOT can be moved similar to a dolly now.
Storage
 • AlwaysstoretheOrbotwiththebaseintheuprightposition.
 • ForstoringtheOrbotintightspaces,werecommendthatyoufolddownthehandleframe.Open
the star-shaped screw knobs on the upper latch brackets by turning them counterclockwise. Fold
down the loosened screw caps. The handle can now be folded down (Fig.22).
Fig. 22
 • IMPORTANT:TheOrbotshouldonlybestoredindryconditions!
