ADDITIONAL INsTRUcTIONs
Weight Kit Installation
• Thetotalweightoftheweightkitis40lbs.
• Puttheweightsontopofthewhitemountingplateslocatedonthesidesofthemachinebase.
Fig. 27 Fig. 28
 • Putthefourscrewsintotheholesprovidedontheweightplatesandfastenbyturningclockwise.
Once the screws have threaded at least 5 full turns, tighten the wing nuts by turning them
clockwise,untiltheweightstsecurelytothebase.
 • WARNING:Makesurethattheweightsaresecurelyattachedtothebase.Looseweightscan
cause serious damage.
 • Forstorageandtransportwerecommendremovingtheweightkit.Themachinecanbetransported
more easily without the weights.
HOS Brush Installation
 • Putthemachinebaseinanuprightposition,sittingonthefootofthebumper.
 • Removethedriverplatebyremovingthefourcountersinkscrewsinthecenteroftheplateusing
an electric screwdriver.
 • WARNING:ItisimportanttoonlyuseaPH3screwdriverbit.Smallerbitsizescandamagethe
screwheadsandleavesharpedges,whichcantearorsnagtheSuperZorbPads.
 • MounttheHOSbrushwiththesamecountersinkscrewsusedformountingthedriverplates.
 • IMPORTANTSAFETYINSTRUCTION:Tightenthescrewssufcientlytoavoiddisengagementofthe
brush from the machine during operation.
To avoid stripping the screws do not over tighten. An electric screwdriver with a clutch will ensure
that stripping will not occur.
 • ForfurtherinstructionsforthestorageoftheHOSbrushseepage15.
Changing the Water Bottle
 • Toputthewaterbottleinthecageholder,placethebottleatanangleoverthecagehoop.Push
the bottle into the cage hoop so that you can push it without much effort into the cage hoop holder.
Pushthebottledownuntilitrestsrmly(seegure7-9,page5)
 • Toremovethewaterbottlefromthecageholder,proceedinreverseorder:Pullthewaterbottle
out of the holder, as soon as the bottom of the bottle hits the cage hoop, tilt the bottle and pull it up
andoutatanangle.Removethebottlefromthecageholderandplaceitnexttothemachineonthe
oor(gure29-31).
