Customizing Your Ampero
GLOBAL
Use the GLOBAL menu to set Ampero’s global functions, including I/O and MIDI channel settings. You can also return to factory settings from this
menu.
Global settings will affect Ampero’s overall working status. These will override any other settings made to your patches. Any changes made in
Global setting will be automatically saved and immediately operational.
In the main menu, press GLOBAL to enter the global settings menu. The screen will look like this:
You can either use the touchscreen or turn the main knob to scroll
through the menu targets. As you select your menu target, buttons
will appear in the selection panel.
The selection panel will display the adjustable options of the target
you select. These will vary according to the selection. If there are
more than three options in the current selection, use the arrows to
the right and left to scroll through the options.
Note: If there is no option in the panel above a certain quick access
knob, moving that knob will have no effect.
DES I GN IN S PIRAT ION
Selectionpanel
Submenu
Exitthemenu
14
Cancel saving and exit Confirmsaving
Selectapatchlocationtosave
Deletesunwantedcharacters

<>:Change Patch
<<>>:Change Bank
Changesthecursorposition
Numeric keyboard
Space
Lower/uppercase
SAVE
In the SAVE menu, you can save the changes your made to your effects parameters, control information, and other editable targets.
It is very important to save the changes you made to your tone and control settings!

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Hotone Ampero MP-100N and is the answer not in the manual?

Hotone Ampero MP-100N Specifications

Digital Audio Processing IconDigital Audio Processing
bit depth24-bit
sample rate44.1kHz
signal-to-noise ratio120dB
Effects and Patches IconEffects and Patches
effects261
simultaneous effects modules9
patches198 (99 user patches, 99 factory patches)
Looper and Drum Machine IconLooper and Drum Machine
looper time mono100 seconds
looper time stereo50 seconds
internal drum machine rhythm patterns100
Inputs and Outputs IconInputs and Outputs
instrument input1/4” Tip Sleeve (TS) Instrument jack
auxiliary input1/8” Stereo Auxiliary In (Aux In) jack
expression pedal input1/4” Tip Ring Sleeve (TRS) Expression Pedal input jack
MIDI inputStandard 5 pin MIDI input jack
unbalanced stereo outputTwo 1/4” Tip Sleeve (TS) Unbalanced Stereo output jacks
balanced stereo outputTwo XLR Balanced stereo output jacks, with ground lift switch
headphones output1/8” Stereo headphones output jack
Resistance IconResistance
instrument input resistance (E.GT)1MΩ
instrument input resistance (A.GT)4.7MΩ
line input resistance10kΩ
aux in resistance10kΩ
unbalanced output resistance3.2kΩ
balanced output resistance2kΩ
headphones resistance66Ω
Display and Connectivity IconDisplay and Connectivity
screen size4”
screen resolution800 x 480
screen typeColor Dynamic Display Touch Screen
USB portUSB 2.0 Type-B port, supports USB Audio 2.0
Power Requirements IconPower Requirements
voltage18V DC Center Negative
current consumption500mA Max
Physical Dimensions IconPhysical Dimensions
width320mm
depth147mm
height46mm
weight1408g
