SEQUENCE CHART
PREWASH
Drain and reset alternating wash valve to Position 0 X X X X X X X X X 30'' Open
Fill 2 litres static via water turbine X X X X
Verify Pressure Switch Closed X X X X Closed
Fill 2.7 Litres & Circulate X X X X
Circulate X X X X 20''
Circulate Alternating Valve Position 1 &
Verify Pressure Sensor Closed
X X 18'
Circulate Alternating Valve Position 1 &
Verify Pressure Sensor Closed
X6'
Circulate Alternating Valve Position 1 &
Verify Pressure Sensor Closed
XX 5'
Circulate & Turbidity Sensor Reading X
Circulate & Heat Alternating Valve Position 2
& Verify Pressure Sensor Closed
X40°C X
Drain X X X X 60''
Drain and reset alternating wash valve to Position 0 X X X X 15'' Open
Fill 2 litres static via water turbine X
Verify Pressure Switch Closed X
Fill 2 Litres via water turbine & Circulate X
Fill further 2 Litres if Pressure Switch is open
maximum 2 minutes
X X 120''
Circulate & Turbidity Sensor Reading X
Circulate Alternating Valve Position 1 &
Verify Pressure Sensor Closed
XX3'
Drain X 60''
Drain and reset alternating wash valve to Position 0 X 15''
WASH
Fill 2 litres static via water turbine X X X X X X X
Verify Pressure Switch Closed X X X X X X X Closed
Fill 2 Litres via water turbine X X X X X X X
Fill further 2 Litres if Pressure Switch is open
maximum 2 minutes
X X X X X X X 120'' Closed
Regenerate & Circulate X X 60''
Detergent & Circulate X X X 60''
Circulate & Turbidity Sensor Reading X
Detergent & Circulate X X X X 60''
Heat & Circulate Alternating Valve Position 1 X42°C X42°C X51°C
Circulate in Alternating Valve Position 2 X 5'
Circulate & Heat Alternating Valve Position 2
& Verify Pressure Sensor Closed
X63°C X48°C X52°C X48°C X
Circulate Alternating Valve Position 2 &
Verify Pressure Sensor Closed
X X X 20'
Circulate Alternating Valve Position 2 &
Verify Pressure Sensor Closed
XX6'
Circulate Alternating Valve Position 2 &
Verify Pressure Sensor Closed
X X 10'
Drain XXXXX X 60''
Drain and reset alternating wash valve to Position 0 X X X X X X 15'' Open
Fill 1 Litre X X X
Drain X X 30'' Open
Fill 1 Litre X X
Drain X X X 30'' Open
COLD RINSE
Fill 2 litres static via water turbine X X X X X
Verify Pressure Switch Closed X X X X X Closed
Fill 2 Litres via water turbine & Circulate X X X X X
Fill further 2 Litres if Pressure Switch is open
maximum 2 minutes
X X X X X 120'' Closed
Intensive
Eco
Normal
Fast
Pre-Wash
Crystal
Special
Pressure Sensor
Wash
Time
Pressure Switch
Selected
Normal
Auto Duo
Guest
Drying
To Next Page
