Installation Instructions
NOTE: Watkins Manufacturing Corporation recommends that the BOLT be installed on a minimum 10 cm thick reinforced concrete pad or structurally
sound deck able to support the “dead weight” found in the spa specification chart.
WARNING: The BOLT must not be shimmed in any manner.
BOLT
80” (203 cm)
80"
(203 cm)
3.5" (9 cm)
29.5 " 75 cm)
33" (84 cm)
65 1/2" (166.4 cm)
18.5” (47 cm)
65” (165 cm)
34” (86.5 cm )
(Bottom view) Upside Down View
of Spa
(Front view)
BOLT (MODEL BLTE)
Dimensions
NOTE: All dimensions are approximate; measure your spa before making critical design or
pathway decisions.
Door
Door
Door
Drain
Electrical Cutout 1 3/4" (4.5 cm)
