HOTSY 965SS-1075SS • 9.807-621.0 • Rev. 09/18
OPERATOR’S MANUAL
PRESSURE WASHER
20
EXPLODED VIEW PARTS LIST
ITEM PART NO. DESCRIPTION QTY
1 8.711-785.0 Hose, 3/8" Push On 38"
2 9.800-049.0 Label, Manufacturers 1
Cleaning Solution
3 8.719-913.0 Top Hat, Weld Assy, 16" 1
4 9.802-904.0 Insulation Top head 16" x 8" 1
5 9.803-108.0 Ring, Insul Retainer, 16" 1
6 8.718-980.0 Washer, 5/16" Flat Sae 8
7 9.802-776.0 Nut, 5/16, Esna, Nc 8
8 8.901-172.0 Label, Detergent Metering 1
9 8.901-136.0 Label, Use Hotsy Detergent 1
10 9.802-771.0 Screw, 10/32" x 3/4"
(1065SSE,1075SSE) 2
( 965SS,1065SS) 3
11 9.802-809.0 Washer, 1/2" Flat Sae 4
12 9.802-695.0 Nut, 10/32" Keps
(1065SSE,1075SSE) 2
( 965SS,1065SS) 3
13 8.920-175.0 Battery Bracket 1
(Battery Models Only)
14 8.905-699.0 Box, Battery 1
(Battery Models Only)
15 8.718-582.0 Bolt, 1/4-20 X 1/2", NC HH 2
16 8.901-135.0 Label, Caution Winterize 1
17 8.900-285.0 Label, Warning Pictorial 1
18 9.802-768.0 Screw, 3/8" x 1-1/4", Whiz 4
Loc Flange
19 9.802-754.0 Screw, 1/4" x 1/2" Nc, 1
Whiz Loc Flange
20 8.911-826.0 Chassis 1
8.911-825.0 Chassis (965SS Only) 1
21 8.901-157.0 Label, Important: Battery 1
22 8.901-127.0 Label, Caution, Gasoline 1
23 8.901-133.0 Label, Warning, Carbon 1
Monoxide
24 8.901-206.0 Label, Hww Geng Instr 1
25 8.925-218.0 Spare Coil Assy Hotsy 1
790 MTY
8.925-219.0 Spare Coil Assy Hotsy
555 MTY 1
26 9.802-825.0 Clip, Retaining U-Type 4
27 8.911-802.0 Coil Wrap (965SS Only) 1
8.911-800.0 Coil Wrap 1
28 8.901-214.0 Label, Hotsy Logo 4 x 9 2
29 8.901-171.0 Label, Troubleshooting 1
30 9.802-903.0 Insulation Bottom 16" 1
31 9.803-544.0 Grommet 1
32 9.802-064.0 Grommet (Nozzle Holder) 3
33 9.802-104.0 Bushing, 1' Snap 2
(965SS) 3
34
77-31620-2GS-003
Voltage Reg
1
(
1065SSE, 1075SSE) 1
9.802-531.0 Voltage Reg. (965SS, 1065SS)
ITEM PART NO. DESCRIPTION QTY
35 8.706-937.0 Reducer, M12 To 1/4" F 1
36 9.802-802.0 Washer, Flat 1/4 14
37 8.754-435.0 Wheel & Pu Tire Assy, 12"
Steel Rim 4
38 9.182-506.0 Cap Black Plastic, 5/8" 4
39 8.718-870.0 Nut, .61 Id, Push Flat 4
40 8.751-374.0 Spacer 5/8 X 1,25 Black 8
41 8.706-744.0 Plug, plastic 1' 2
42 8.750-576.0 Engine Honda (965SS) 1
8.750-577.0 Engine Honda (1065SS) 1
8.750-578.0 Engine, Honda E Start
(1065SSE) 1
8.750-579.0 Engine, Honda E Start
(1075SSE) 1
43 8.901-118.0 Tag, Gasoline Engine 1
44 8.932-992.0 Mount , Vibration, 3/8" 4
Rubber 70 Dura
45 9.802-728.0 Bolt, 3/8-16 x 2", Hh Zinc 4
46 9.802-776.0 Nut, 5/16, Esna, Nc 8
47 9.198-014.0 Washer 21/64 x 1" 4
48 8.912-017.0 Lever, Brake, Red 1
49 8.912-020.0 Linkage, Brake, Red 1
50 8.912-019.0 Bracket, Brake Pad, Red 1
51 9.802-705.0 Bolt, 1/4-20 x 1", 4
Carriage, Zinc
52 9.802-773.0 Nut, 1/4-20 Esna Nc 4
53 9.198-004.0 Washer, 3/8" Flat Zinc 4
54 9.802-814.0 Washer, 3/8" Split Ring 4
Lock, Zinc
55 9.800-018.0 Label, Tip Over Hazard 1
56 8.706-321.0 Cap, Pipe, 1/8" Npt Brass 1
57 8.706-940.0 Hose Barb, 1/4" x 1/8" Mpt 1
58 6.390-126.0 Clamp, Hose, .46-, .54 St 2
59 9.802-254.0 Hose, 1/4" Push On 3"
60 8.706-941.0 Hose Barb, 1/4" x 1/4" Mpt, 1
Brass
61 8.707-206.0 Valve, Mini Oil Drain 1
62 8.709-117.0 Clamp, Hose, Uni .62-.75 St 1
63 9.802-959.0 sKey, 0.247 Sqr x 2.125" 1
64 8.756-871.0 Label, P65 Warning, Gas 1
65 8.706-731.0 Bushing, 3/4" 2
66 8.717-438.0 Insulation Blanket 22" x 52" 1
(1065SS, 1065SSE,
1075SSE)
9.802-908.0 Insulation Blanket 18" x 52" 1
(965SS)
67 8.716-608.0 Terminal, Battery, Marine 2
(Battery Models Only)
68 9.802-819.0 WASHER, 7/16" x 2 1/2", ZINC,
PG FOOT 3
69 9.802-710.0 Screw 5/16" x 1"NC 3
sNot Shown
To Next Page
