HOTSY 965SS-1075SS • 9.807-621.0 • Rev. 09/18
25
PRESSURE WASHER
OPERATOR’S MANUAL
Replacement Parts
For best performance specify genuine WAYNE replacement parts
WAYNE BURNER PARTS LIST (965SS ONLY)
ITEM PART NO. DESCRIPTION QTY
1 101409-001 Tube/Hous-101393-001/3A/3.75"/.88"I 1
2 8.756-437.0 Pump-Combo/W Solenoid 12V/24V 1
3 550053 Fitting, Elbow 90* Street 1/8 1
4 01274-001 Tee,Street-1/8 x 1/8 Brass 1
5 14222 Connector, Male-3/16" x 1/8" IPT 1
6 15766 Plug, Pipe HXHD 1/8" NPT 1
7 9.107-507.0 Ignitor-MSR 12V LA 1
11 21723-014 Cover, Hous-M CAD MTG & Gasket 1
12 101309-002 Base, Mounting-Ignitor CC Timer 1
13 8.756-661.0 Timer, Drop-Out 1
15 8.700-719.0 Cad Cell F/HS & M Series Burner 1
17 8.700-739.0 Motor, 12VDC 1/8HP LOWAMP/3950RPM 1
18 100761-001 Sideplate, Housing-MSR 12VDC 1
21 8.756-674.0 Fan-3.44"W x 4.25"D 5/16" Bore 1
23 8.700-707.0 Air Band Inner "M" 1
24 8.717-826.0 Air Band Outer 8 Hole "M" 1
26 8.756-295.0 Junction Box, MSR 1
28 13392 Plate, Slot Cover 1
30 8.700-704.0 Oil Line Assembly 6" 1
34 8.756-297.0 Gun Assembly, Burner-RG/*CST/* 1 1/4"BB 1
35 8.700-721.0 Coupling, "M" DC 1
50 8.700-692.0 Flange Gasket (2 Each) 2
51 8.717-939.0 Burner Fan Housing "M" Drilled 1
52 8.700-701.0 Air Cone #3A 1
53 8.756-303.0 Air Tube Flange Welded .88" "MSR" 1
sNot Shown
