HOTSY 965SS-1075SS • 9.807-621.0 • Rev. 09/18
33
PRESSURE WASHER
OPERATOR’S MANUAL
HS.3 PUMP EXPLODED VIEW PARTS LIST
ITEM PART NO. DESCRIPTION QTY
50* See Kit Below O-Ring Ø1.78x5.28 3
51* See Kit Below Teon Ring 3
52 8.751-225.0 Plunger Rod 3
53 8.751-228.0 Connecting Rod Pin 3
54 9.803-158.0 Connecting Rod 3
55 9.803-218.0 Spring Washer 6
56 9.803-238.0 Connecting Rod Screw 6
57 8.933-016.0 O-Ring 2.62 x 126.67 1
58 8.751-229.0 Crankcase Cover 1
59 9.803-197.0 O-Ring, Ø 1.78 x 14 1
60 9.803-202.0 Sight Glass, G3/4 1
* Part available in kit (See below)
REPAIR KIT NUMBER 8.725-358.0 8.725-359.0 8.933-023.0 9.802-603.0 9.802-609.0
KIT DESCRIPTION
Plunger U-Seal
15mm
Complete
U-Seal Packing 15mm Plunger 15mm Complete Valve
Plunger Oil
Seals
ITEM NUMBERS
INCLUDED
3, 5, 7 3, 4, 5, 6, 7
46, 47, 48, 49,
50, 51
11, 12, 13 2
NUMBER OF CYLINDERS
KIT WILL SERVICE
3 1 1 6 3
