Hotsy Gas Belt Drive • 8.931-236.0 • REV. 7/13
OPERATOR’S MANUAL
PRESSURE WASHER
20
EXPLODED VIEWS PARTS LIST
ITEM PART NO. DESCRIPTION QTY
1 8.931-194.0 Assy, Hotsy 1100 Cage 1
2 8.931-270.0 Coil, Blt Drv Roll Cage 1
3 8.916-076.0 Outer Wrap, Red 1
4 8.911-954.0 Plate Insulation Retainer 1
5 8.719-946.0 Hanger, Hose 1
6 8.719-935.0 Ring, Insul Retain 1
7 8.911-327.0 Top Hat, Weld Assy, 18"
Hotsy Coils 1
8 9.802-825.0 Clip, Retaining U-Type 4
9 8.912-129.0 Strap, Coil 1
10 8.717-442.0 Insulation, Top Head
18 OD x 8.0 ID, Fiberglass 1
11 8.751-741.0 Insulation, Pancake 14" 1
12 8.709.153.0 Filter, Fuel, Hotsy 3/8" 1
13 8.706-958.0 Hose Barb,
1/4" Barb x 1/4" ML Pipe 1
14 9.802-254.0 Hose, 1/4 Push-on 48"
15 8.706-546.0 Grommet, 1-3/4" x 2-1/8" x 3/8" 3
16 8.706-547.0 Grommet, 1/2" x 1" x 1/2" 3
17 8.706-553.0 Mount, Rubber 60 Duro 8
18 8.717-451.0 Insl, 1/2" Cerflt SB Lin Ft 59 in
19 8.931-243.0 Hose Reel Bracket 1
20 8.915-292.0 Hose Reel Retainer 2
21 6.390-126.0 Clamp, Hose, .46-,54 ST 6
22 8.900-282.0 Label, RPM 1
23 9.800-008.0 Label, Danger Cool Engine 1
24 9.802-794.0 Cage Nut, 1/4 x 12 Ga. 2
25 8.706-600.0 Battery, Box, Large (1075BE,
1080BE) 1
26 8.705-975.0 Nipple, 1/2" Hex Steel 1
27 8.706-216.0 Tee, 1/2" Female, Steel Pipe 1
28 9.802-038.0 Nipple, 1/2 JIC, 1/2 Pipe (Steel) 1
29 8.706-243.0 Plug, 1/2" Square, Head, Galv 1
30 9.802-776.0 Nut, 5/16" ESNA 4
31 9.800-001.0 Label, Gas Only (1080BE) 1
32 9.802-756.0 Screw, 5/16" x 1" Whiz 3
(1080BE) 2
33 8.719-000.0 Washer, 5/16" x 1-1/4"
Fender, SAE 7
34 9.802-778.0 Nut, Whiz Loc 5/16 Flange 9
35 9.803-277.0 Screw, 5/16" x 1/2" Whiz Loc 6
36 9.802-733.0 Bolt, 3/8 x 3-1/2" 1
37 9.802-254.0 Hose, 1/4 Push-on 30"
38 9.802-779.0 Nut, 3/8 ESNA 15
39 9.802-807.0 Washer, 3/8", SAE, Flat 17
40 9.802-531.0 Regulator, Voltage 15 Volt,
9 HP Only 1
ITEM PART NO. DESCRIPTION QTY
41 9.802-203.0 Clamp, 1/2" RO-Clip,
Kleinhuis 1
(1080BE) 2
42 9.802-771.0 Screw, 10/32 x 3/4" BH SOC CS
(1080BE, 1075BE) 4
(965B) 5
43 9.802-695.0 Nut, 10/32" Keps 4
(965B) 5
44 9.802-754.0 Screw, 1/4" x 1/2" HH NC,
Whiz Loc 4
45 9.802-207.0 Clamp, Round 0.56 ID (Honda) 1
46 9.802-767.0 Screw, 3/8" x 3/4" HH NC, Whiz 2
47 8.718-636.0 Bolt, 5/16" x 3", NC HH Zinc 1
48 9.800-006.0 Label, "Hot/Caliente" with
Arrows Warning 4
49 8.932-968.0 Label, For Outdoor Use-USA 1
50 9.800-034.0 Label, Clear Lexan, 4.5" x 4.90" 1
51 8.931-277.0 Label, Hotsy Roll Cage
Deck Plate 1
52 8.918-211.0 Hose, 3/8" x 40", 2 Wire
1/2" FJIC x 1/2"FJIC 1
53 9.802-151.0 Swivel, 1/2" JIC Fem Push-on 2
54 9.802-259.0 Hose, 1/2" Push-on per/ft 10 in
55 8.918-425.0 Hose, 3/8" x 29" 2 Wire
Pressure Loop 1
56 8.931-214.0 Platform, Power Assy 1
57 8.715-070.0 Engine, Gas Elec/Mnl
Briggs (1080BE) 1
8.750-579.0 Engine, Honda GX390UT2QNR2
E/S 18 Amp (1075BE) 1
8.750-576.0 Engine, Honda, GX270UT2QAR2
18 Amp (965B) 1
58 9.802-384.0 Pulley, 2 BK 40H (1080BE) 1
8.715-576.0 Pulley, 2BK 32H (1075BE,
965B) 1
59 8.715-593.0 Pulley, 2BK 90H (1080BE,
1075BE) 1
8.715-591.0 Pulley, 2 BK 70H
(965B) 1
60 9.802-399.0 Bushing H x 1 1
61 9.802-402.0 Bushing, H x 24mm 1
62 9.802-673.0 Key, Shaft, 16 HP Vanguard 1
63 8.715-695.0 Belt, Bx34 (1080BE, 1075BE) 2
9.804-525.0 Belt, BX33 (965B) 2
64 9.802-716.0 Bolt, 5/16" x 2" NC HH
(1080BE) 4
9.802-727.0 Bolt, 3/8" x 1-3/4" Tap (1075BE,
965B) 4
65 9.802-776.0 Nut, 5/16" ESNA NC
(1080BE) 4
9.802-779.0 Nut, 3/8" ESNA NC (1075BE,
965B) 4
To Next Page
