Hotsy 1075BE - Pump and Unloader Parts List

Hotsy Gas Belt Drive • 8.931-236.0 • REV. 7/13
27
PRESSURE WASHER
OPERATOR’S MANUAL
ITEM PART NO. DESCRIPTION QTY
1 8.751-181.0 Pump, Hotsy HM-4035-L
(1080BE, 1075BE) 1
8.749-159.0 Pump, Hotsy HD3030L,
3 @ 3000,1650 RPM (965B) 1
2 9.802-146.0 Swivel, 1/2" x 3/4" 1
3 8.706-915.0 Bushing, 1/2" x 1/4" Brass 1
4 8.706-958.0 Hose Barb, 1/4" Barb x 1/4"
Pipe 90° 1
5 9.802-632.0 Cap, Valve w/1/4 Port 1
6 8.750-299.0 Unloader, VRT3,
8 GPM @ 4500 PSI 1
7 9.802-131.0 Elbow, 1/2" JIC x 1/2" MPT,
90° 1
8 9.804-022.0 Cap, Valve w/1/4 Port
(965B) 1
9 9.802-039.0 Elbow, 1/2" JIC, 3/8 MPT 1
10 8.706-829.0 Elbow, 1/2" Street 1
11 8.707-254.0 Pump Protector, 3/8" 145° 1
12 9.802-039.0 Elbow, 1/2 JIC x 3/8" Pipe 1
13 9.802-151.0 Swivel, 1/2" JIC FEM,
Push-on 2
14 9.802-259.0 Hose, 1/2" Push-on per/ft 16 in
15 9.802-126.0 Plug, 1/2" JIC, Flare, 639F-8 1
16 9.802-807.0 Washer, 3/8, SAE Flat 4
PUMP AND UNLOADER EXPLODED VIEW PARTS LIST
ITEM PART NO. DESCRIPTION QTY
17 9.802-814.0 Washer, 3/8" Lock,
Split Ring 4
18 9.802-744.0 Bolt, 10mm x20mm, HH 4
19 8.915-285.0 Pump Slider 1
20 9.802-039.0 Elbow, 1/2" JIC x 3/8" MPT 1
21 9.802-048.0 Swivel, 1/2" JIC Fem, 3/8" Mal 1
22 8.751-265.0 Valve, EZ Start,
3/8" NPT, 5/16" Hose Barb 1
23 8.706-207.0 Elbow, 3/8", Street 90° 1
24 9.802-458.0 Switch, Pressure N/O,
1/4 NPT SS 1
25 9.802-129.0 Elbow, 1/2" x 3/8" 90° 1
26 9.802-741.0 Bolt, 8mm x 16mm
Hex Head 4
27 8.718-980.0 Washer, 5/16, Flat, SAE 4
28 9.802-813.0 Washer, 5/16", Lock,
Split Ring 4
29 9.802-254.0 Hose 1/4" Push-on
Fuel Line per/ft 14 in
30 6.390-126.0 Clamp, Hose, .46-, 54 ST 2
31 9.802-869.0 Block Unloader, 1/2 x 1/2,
1.75 Steel 1
32 9.802-040.0 Elbow, 1/2 JIC, 1/2, 90° 1
33 9.802-038.0 Nipple, 1/2 JIC Pipe (Steel) 1
34 8.706-860.0 Tee, 1/2 Street, Brass 1
