Hotsy 1075BE User Manual

Hotsy Gas Belt Drive • 8.931-236.0 • REV. 7/13
33
PRESSURE WASHER
OPERATOR’S MANUAL
Item # Part # Description Qty Item # Part # Description Qty
1 8.919-050.0 BURNER HOUSING ASSEMBLY 1 25 8.750-830.0 PLUG, HOLE 0.285 PLASTIC 1
2 8.751-160.0 AIR GUIDE 26 8.751-134.0 PLUG, 1/8" NPT x HEX SHOULDER 1
3 8.700-758.0 FUEL PUMP, SUNTEC A2VA-3106 12-24V SOL 1 27 8.918-454.0 GASKET, JUNCTION BOX 1
3 8.700-759.0 FUEL PUMP, SUNTEC A2VA-3106 120V SOL 1 28 8.750-542.0 COVER, JUNCTION BOX 1
3 8.700-760.0 FUEL PUMP, SUNTEC A2VA-3106 230V SOL 1 29 8.750-116.0 BLOCK, TERMINAL, 5 POLE 1
3 8.753-000.0 FUEL PUMP, DANFOSS 071N1298 1 30 8.750-817.0 LIGHT, INDICATOR, GREEN 14V 2
4 8.750-762.0 COIL, SOLENOID DANFOSS 230V 1 30 8.750-818.0 LIGHT, INDICATOR, GREEN 28V 1
4 8.750-763.0 COIL, SOLENOID DANFOSS 115V 1 30 8.750-819.0 LIGHT, INDICATOR, GREEN 125V 1
4 8.750-764.0 COIL, SOLENOID DANFOSS 12-24V 1 30 8.750-820.0 LIGHT, INDICATOR, GREEN 250V 1
5 8.750-765.0 CABLE, SOLENOID COIL, DANFOSS 1 31 8.750-784.0 SITE GLASS 1
5a 8.750-783.0 MOUNTING KIT, FLANGE/HUB, DANFOSS 1 32 8.750-785.0 RING, PUSH ON INTERNAL, 1305-112 1
6 8.750-541.0 AIR BAND 1 33 8.733-001.0 SCREW, 8 x 1/4" HI LOW THREAD CUT, PPH 2
7 8.750-517.0 MOTOR, 1/6 HP 115V 60Hz 1 34 8.718-762.0 SCREW, 8-32 X 1/2", M PH RDH PL 2
7 8.750-518.0 MOTOR, 1/6 HP 230V 60Hz 1 35 8.752-137.0 WASHER, COPPER 1
7 8.751-074.0 MOTOR, 1/7 HP 12VDC AMETEK 1 36 8.718-810.0 SCREW, 10/32 x 1/2", WHIZ LOC FLANGE 6
8 8.750-543.0 COUPLING, FLEX, 1/2" x 5/16" 1 37 8.750-770.0 SCREW, 10/32 x 5/8", WHIZ LOC FLANGE 3
8 8.751-073.0 COUPLING, FLEX, 5/16" x 5/16" 1 38 8.750-816.0 SCREW, 10/32 X 1/4" GROUNDING 1
9 8.750-520.0 FAN, 4.53" X 2.42", 1/2" BORE, F115-62S 1 39 8.750-768.0 SCREW, 1/4-20 x 1", WHIZ LOC FLANGE 4
9 8.751-072.0 FAN, 4.53" x 2.42" x .313 BORE, F115-625 1 40 8.750-771.0 SCREW, 1/4-20 X 1/2", PHIL FHMS 4
11 8.750-547.0 CONNECTOR, 37 DEG FLARE X 1/8" NPT, LONG 1 42 — LABEL, BRAND NAME 1
12 8.750-545.0 CONNECTOR, 37 DEG FLARE X 1/8" NPT 1 43 9.801-268.0 LABEL, DISCONNECT POWER SUPPLY 1
13 8.749-000.0 FUEL LINE ASSEMBLY 1 44 — LABEL, SERIAL PLATE 1
14 8.752-034.0 FLANGE, KNA BURNER, 1" TUBE 1 46 9.807-339.0 LABEL, WIRING DIAGRAM, BURNER 115V-115V 1
15 8.752-035.0 FLANGE, KNA BURNER, 3" TUBE 1 46 9.807-340.0 LABEL, WIRING DIAGRAM, BURNER 230V-230V 4
16 8.750-539.0 GASKET, FLANGE 1 46 9.807-341.0 LABEL, WIRING DIAGRAM, BURNER 230V-115V 1
18 8.750-526.0 GUN, ELECTRODE / NOZZLE, 3" 1 46 9.807-342.0 LABEL, WIRING DIAGRAM, BURNER 115V-24V 1
19 8.750-525.0 GUN, ELECTRODE / NOZZLE, 1" 1 46 9.807-343.0 LABEL, WIRING DIAGRAM, BURNER 230V-24V 1
20 Varies NOZZLE, FUEL 1 46 9.807-344.0 LABEL, WIRING DIAGRAM, BURNER 12VDC 1
21 8.750-778.0 ELECTRODE, IGNITION, AC 1 48 9.801-274.0 LABEL, BURNER LIGHTS 1
21 8.751-342.0 ELECTRODE, IGNITION, DC 1 49 8.919-105.0 PLATE, TERMINAL BLOCK NUMBERS 1
22 8.750-779.0 CONE, AIR F4 1 50 8.716-451.0 TERMINAL, JUMPER SPADE 1
22 8.750-782.0 CONE, AIR F6 1 51 9.802-510.0 CABLE, TIE, 4" BLACK 2
22 8.750-780.0 CONE, AIR F12 1 52 9.807-348.0 LABEL, CLEAR MYLAR 1
22 8.750-781.0 CONE, AIR F22 1 53 9.807-345.0 LABEL, IGNITER 120V 1
23 8.919-114.0 IGNITOR, BURNER 120V 1 53 9.807-346.0 LABEL, IGNITER 230V 1
23 8.919-115.0 IGNITOR, BURNER 230V 1 53 9.807-347.0 LABEL, IGNITOR 12VDC 1
23 8.919-116.0 IGNITOR, BURNER 12VDC 1 54 8.751-354.0 GASKET, BURNER TUBE 1
24 8.751-165.0 PLUG, HOLE 0.875 PLASTIC 1
For best performance specify genuine Crossfire replacement parts
REPLACEMENT PARTS LIST
