Hotsy 1075BE - HM.3 Series Pump Parts List

Hotsy Gas Belt Drive • 8.931-236.0 • REV. 7/13
31
PRESSURE WASHER
OPERATOR’S MANUAL
HM.3 SERIES PUMP EXPLODED VIEW PARTS LIST
ITEM PART NO. DESCRIPTION QTY
38*
See Kits Below Teflon Ring 3
35*
See Kits Below Plunger (4035) 3
See Kits Below Plunger (3540) 3
39 9.803-144.0 Plunger Rod 3
40 9.803-158.0 Connecting Rod 3
41 8.751-228.0 Connecting Rod Pin 3
42 9.803-218.0 Spring Washer 6
43 9.803-238.0 Connecting Rod Screw 6
44 70-060009 O-Ring, Ø2.62 x 126.67 1
45 8.751-229.0 Crankcase Cover 1
46 9.803-197.0 O-Ring, Ø1.78 x 14 1
47 9.803-202.0 Sight Glass 3/4 1
48 9.802-939.0 Cover Screw 5
* Available in kit (See below)
REPAIR KIT NO. 8.725-360.0 8.725-358.0 8.725-361.0 8.725-359.0 8.751-237.0 8.933-023.0 9.802-603.0 9.802-609.0
KIT
DESCRIPTION
Plunger Seal
4035
18mm
Plunger Seal
3540
15mm
Complete
Seal
Packing
4035
18mm
Complete
Seal
Packing
3540
15mm
Plunger
4035
18mm
Plunger
3540
15mm
Complete
Valve
Plunger Oil
Seals
ITEM NUMBERS
INCLUDED
3, 5, 7 3, 5, 7 3, 4, 5, 6, 7 3, 4, 5, 6, 7
33, 34, 35,
36, 37, 38
33, 34, 35,
36, 37, 38
11, 12, 13 2
NO. OF CYLIN-
DERS KIT WILL
SERVICE
3 3 1 1 1 6 3
