45Hotsy 900/1400 Series Dealer Manual 9.803-324.0 - AW
Electrical Box
REF PART NO. QTY DESCRIPTION NOTES
7 8.716-199.0 1 FUSE, FNM-6.25
8 8.718-936.0 10 SCREW, #8 X 1/2" PHILLIPS ZINC TEK
9 9.802-457.0 10" DIN RAIL, 35MM
10 9.802-457.0 3" DIN RAIL, 35MM
11 9.804-595.0 4 END BRACKET, ENTRELEC 103-002-26
12 8.756-361.0 1 RELAY, SMART, 24V, 8I/40, FS
- 8.918-471.0 1 PROGRAMMED, SMART RELAY, STATIONARY
PRE PROGRAMED
REPLACEMENT PART
13 7.749-976.0 5 TERMINAL BLOCK FEED THROUGH, PHOENIX,
3 WIRE
14 8.753-064.0 11 TERMINAL BLOCK FEED THROUGH, PHOENIX,
2 WIRE
15 8.716-449.0 2 COVER, FUSE PROTECTOR
16 8.749-977.0 3 BAR, JUMPER, FSB 2-5GY
17 8.753-252.0 1 TERMINAL BLOCK, END CAP
18 6.643-249.0 1 TERMINAL, STRIP
19 9.802-519.0 2 STRAIN RELIEF, 1/2", METAL
20 8.718-937.0 3 SCREW, #8 X 3/4" PHILLIPS, ZINC PLTD
21 8.750-095.0 1 THERMOSTAT, 120C/248F 2 METER CAPILLARY
22 9.802-518.0 1 STRAIN RELIEF, 3/4"
- 8.716-565.0 2 STRAIN RELIEF,CG100-850,1'PUR (8/4 CORD)
(1452N, 1452P)
- 9.803-280.0 2 LOCKNUT, 1" CONDUIT
(1452N, 1452P)
- 9.802-521.0 2 STRAIN RELIEF, 3/4" PUR
(1743),(1474N, 1474P)
23 8.706-755.0 1 BUSHING, .875, P/N 2119
24 8.712-190.0 1 BEZEL, PLASTIC
25 9.750-097.0 1 KNOB, THERMOSTAT 120C/248F
26 8.718-897.0 4 NUT, 5/16" SPEED
27 8.716-460.0 2 TERMINAL, GROUNDING LUG
28 8.921-218.0 1 Q BAR, PLC
29 8.900-514.0 1 LABEL, VOLTAGE, 208V, 1 PH
(921N, 1451N)
- 9.800-025.0 1 LABEL, VOLTAGE, 230V,1PH,
(943P, 943N,1453P,
1453N,1473P,1473N)
- 8.900-515.0 1 LABEL, VOLTAGE, 208V, 3 PH
(942P, 942N,
1452P, 1452N)
- 9.800-023.0 1 LABEL, VOLTAGE, 230V 3 PH,
(944P, 944N,
1454P,1454N,
1474P,1474N)
- 9.800-024.0 1 LABEL, VOLTAGE, 460V, 3 PH
(945P, 945N,
1455P, 1455N)
- 8.900-516.0 1 LABEL, VOLTAGE, 575V, 3 PH
(926N, 1456N)
30 8.716-598.0 2 STRAIN RELIEF, .18-.31
31 9.800-040.0 3 LABEL, GROUND SYMBOL
32 8.718-779.0 2 SCREW, 4MM X 6MM
33 8.716-216.0 1 HOLDER, FUSE
34 8.716-170.0 1 FUSE, MDL-1/2 250V FUSE
35 8.922-969.0 1 BRACKET, BACK, E-BOX
36 8.751-055.0 4 RIVET, ALUM 3/16" DIA.062-.125 GRIP
37 9.801-488.0 1 LABEL, TERMINAL BLOCK, 12 PIN
38 9.807-875.0 1 PLC LOGIC, STATIONARY HOT WATER, FS
NOT SHOWN
