Hotsy 1473P Dealer's Manual

46
Component Cube
REF PART NO. QTY DESCRIPTION NOTES
1-1MOTOR
SEE SPECIFICATION PAGES
2 - 1 PULLEY
SEE SPECIFICATION PAGES
3 - 1 PULLEY
SEE SPECIFICATION PAGES
4 - 1 BUSHING
SEE SPECIFICATION PAGES
5 9.802-402.0 1 BUSHING, H X 24MM
Hotsy 900/1400 Series Dealer Manual 9.803-324.0 - AW
