Hotsy 1473P Dealer's Manual

47Hotsy 900/1400 Series Dealer Manual 9.803-324.0 - AW
Component Cube
REF PART NO. QTY DESCRIPTION NOTES
6 - 2 BELT
SEE SPECIFICATION PAGES
7 9.802-203.0 1 CLAMP, 1/2"
8 9.802-720.0 4 BOLT, 3/8" X 1" NC HH
9 9.802-807.0 16 WASHER, 3/8" SAE, FLAT ZINC
10 8.718-897.0 4 NUT, 5/16" SPEED
11 9.802-518.0 1 STRAIN RELIEF
(921N, 921P, 926N926P, 942N, 942P,
943N, 943P, 944N, 944P, 945N, 945P,
1451N, 1451P, 1456N, 1456P)
- 8.716-565.0 1 STRAIN RELIEF,CG100-850,1'PUR (8/4 CORD)
(1452N, 1452P)
- 9.803-280.0 1 LOCKNUT, 1" CONDUIT
(1452N, 1452P)
- 8.753-364.0 1 STRAIN RELIEF
(1453N, 1453P, 1454N, 1454P,
1455N, 1455P, 1474N, 1474P,1475N,
1475P)
- 8.753-363.0 1 LOCKNUT 1"
(1453N, 1453P, 1454N,
1454P,1455N, 1455P, 1474N,
1474P,1475N, 1475P)
- 9.802-521.0 1 STRAIN RELIEF
(1473N, 1473P)
- 9.802-523.0 1 LOCKNUT
(1473N, 1473P)
12 9.802-429.0 45" CORD, SERV, 12/4
(926N, 942N, 945N, 1455N, 1456N,
926P, 942P 944P, 945P, 1455P,
1456P)
- 9.802-436.0 45" CORD, SERVICE, 10/3
(921N, 943N, 921P, 943P)
- 9.802-437.0 45" CORD SERVICE, 10/4
(1454N, 1454P)
- 9.802-425.0 45" CORD, SERVICE 8/3
(1451N, 1453N,
1451P, 1453P)
- 9.804-048.0 45" CORD, SERVICE, 6/3
(1473P,1473N)
- 9.802-426.0 45" CORD, SERVICE, 8/4
(1452N, 1452P, 1474P,
1475P, 1474N, 1475N)
13 8.718-760.0 3 SCREW, #8 X 3/4" PHILLIPS
14 8.900-514.0 1 LABEL, VOLTAGE, 208V, 1 PH
(921N, 1451N,
921P, 1451P)
- 9.800-025.0 1 LABEL, VOLTAGE, 230V, 1 PH
(943P, 943N, 1453P,
1453N,1473P,1473N)
- 8.900-515.0 1 LABEL, VOLTAGE, 208V, 3 PH
(942P, 942N, 1452P,
1452N 1475P, 1475N)
- 9.800-023.0 1 LABEL, VOLTAGE, 230V 3 PH
(944P, 944N, 1454P,
1454N,1474P,1474N)
- 9.800-024.0 1 LABEL, VOLTAGE, 460V, 3 PH
(945P, 945N,
1455P, 1455N)
- 8.900-516.0 1 LABEL, VOLTAGE, 575V, 3 PH
(926N, 1456N,
926P, 1456P)
15 9.803-551.0 4 SCREW, 5/16 X 3/4" WHIZ LOC
16 8.921-205.0 1 LABEL, MOTOR ROTATION
17 8.932-965.0 1 LABEL, WARNING, EXPOSED PULLEY
18 9.802-483.0 1 COVER, 2" X 4" METALWEATHER PROOF
19 9.800-040.0 1 LABEL, GROUND SYMBOL
20 8.716-339.0 1 ELEC BOX, 4" X 2"
21 8.753-364.0 1 STRAIN RELIEF
- 9.803-279.0 1 STRAIN RELIEF
(944N, 944P, 1456N, 1456P)
- 9.803-280.0 1 LOCKNUT
(944N, 944P, 1456N, 1456P)
22 9.802-779.0 6 NUT, 3/8" ESNA, NC
