Hotsy 1473P Dealer's Manual

58
VB9 Unloader
REF PART NO. QTY DESCRIPTION NOTES
129.0087.511SST CLIP
2 29.0089.84 1 PLASTIC HOUSING
3 16.3020.00 2 2.5 X 12 MM SCREW
429.0088.841COVER
5 10.3206.01* 1 O-RING, 2.62 X 28.25MM
6 12.5006.00 1 EL. CABLE AND MICROSWITCH
7 29.0109.84 1 RED NUT (25 BAR)
8 10.3169.00* 1 O-RING, 2.62 X 6.02 MM
9 10.3038.00* 1 O-RING, 1.78 X 3.68 MM
10 14.3519.00 1 WASHER, 4 X 8 MM
11 60.2303.51 1 SPRING
12 29.0086.31 1 WASHER, 4 X 16 MM
13 60.2351.31 1 PIN
14 60.2353.31 1 SEAT FITTING
15 10.3165.00* 1 O-RING, 2.62 X 2.84
16 10.4018.00* 1 BACK RING, 3.2 X 7.5 MM
17 30.4115.31 1 M 10 PLUG
18 60.2352.51 1 SST PIN
19 10.3073.00* 1 O-RING, 1.78 X 23.52 MM
Hotsy 900/1400 Series Dealer Manual 9.803-324.0 - AW
921580
8.715-489.0
921580
8.715-489.0
