Hotsy 1473P Dealer's Manual

57Hotsy 900/1400 Series Dealer Manual 9.803-324.0 - AW
HM.3 Series Pump
REF PART NO. QTY DESCRIPTION NOTES
27 8.751-222.0 1 CRANKSHAFT (3540)
- 8.751-223.0 1 CRANKSHAFT (4030, 4035)
- 8.717-063.0 1 CRANKSHAFT (4031)
28 9.803-167.0 1 CRANKSHAFT KEY
29 9.802-921.0 1 OIL DIP STICK
30 9.803-140.0 1 CRANKSHAFT SEAL
31 9.803-178.0 2 SHIM
32 8.717-209.0 1 BEARING HOUSING
33 - 3 PLUNGER NUT, M8 SEE KITS TABLE
34 - 3 COPPER SPACER SEE KITS TABLE
35 - 3 PLUNGER SEE KITS TABLE
36 - 3 COPPER SPACER SEE KITS TABLE
37 - 3 O-RING SEE KITS TABLE
38 - 3 TEFLON RING SEE KITS TABLE
39 8.751-224.0 3 PLUNGER ROD (4030, 4031, 4035)
- 8.751-225.0 3 PLUNGER ROD (3540)
40 9.803-158.0 3 CONNECTING ROD
41 8.751-228.0 3 CONNECTING ROD PIN
42 9.803-218.0 6 SPRING WASHER
43 9.803-238.0 6 CONNECTING ROD SCREW
44 70-060009 1 O-RING, Ø2.62 X 126.67
45 8.751-229.0 1 CRANKCASE COVER
46 9.803-197.0 1 O-RING, Ø1.78 X 14
47 9.803-202.0 1 SIGHT GLASS 3/4
48 9.802-939.0 5 COVER SCREW
REPAIR KIT NO. 8.725-360.0 8.725-362.0 8.725-358.0 8.725-361.0 8.725-363.0 8.725-359.0 8.751-237.0 8.751-238.0
KIT
DESCRIPTION
Plunger
Seal
4035
18mm
Plunger
Seal 4030,
4031
20mm
Plunger
Seal
3540
15mm
Complete
Seal
Packing
4035
18mm
Complete
Seal
Packing
4030, 4031
20mm
Complete
Seal
Packing
3540
15mm
Plunger
4035
18mm
Plunger
4030,
4031
20mm
ITEM NUMBERS
INCLUDED
3, 5, 7 3, 5, 7 3, 5, 7 3, 4, 5, 6, 7 3, 4, 5, 6, 7 3, 4, 5, 6, 7
33, 34, 35,
36, 37, 38
33, 34, 35,
36, 37, 38
NO. OF
CYLINDERS KIT
WILL SERVICE
333 1 1111
REPAIR KIT NO. 8.933-023.0 9.802-603.0 9.802-609.0
KIT
DESCRIPTION
Plunger
3540
15mm
Complete
Valve
Plunger
Oil
Seals
ITEM NUMBERS
INCLUDED
33, 34, 35,
36, 37, 38
11, 12, 13 2
NO. OF
CYLINDERS KIT
WILL SERVICE
163
