59Hotsy 900/1400 Series Dealer Manual 9.803-324.0 - AW
VB9 Unloader
REF PART NO. QTY DESCRIPTION NOTES
20 10.3072.50* 1 O-RING, 1.78 X 21.95 MM
21 10.3070.02* 2 O-RING, 1.78 X 18.77 MM
22 60.0733.35 1 MANIFOLD
23 11.4540.00 1 SST M6 NUT
24 60.2221.20* 1 VB8/9 SEAT AND SHUTTER
25 10.3001.01* 1 O-RING, 1 X 4 MM
26 10.3066.01 1 O-RING, 1.78 X 15.6 MM
27 60.2210.31 1 SPACER
28 60.2202.51 1 VB 9 PISTON
29 10.3170.08 1 O-RING, 2.62 X 7.6 MM
30 10.4021.00 2 BACK RING, 11.4 X 15.9 MM
31 10.3175.00 1 O-RING, 2.62 X 10.77MM
32 28.0013.31 1 BRASS, 1/4 BSP PLUG
33 14.3911.00 1 1/4” COPPER WASHER
34 60.2201.35 1 VB9 BRASS BODY
35 15.1021.00 1 PIN 3 X 14 MM
36 10.3213.00 1 O-RING 3 X 6 MM
37 60.0052.31 1 CHECK VALVE
38 60.0053.51 1 SPRING
39 60.0058.31 1 3/8 BSP F OUTLET FITTING
40 60.2203.61 1 4.2 MM SPRING
41 60.2207.31 1 M8 NUT
42 60.2208.84 1 SPRING WASHER
43 16.2105.00 1 M5 X 6 MM DOWEL
44 60.2252.31 1 SPRING NUT
45 60.2253.31 1 ADJUSTMENT NIPPLE
46 11.4589.10 1 M8 NUT
47 16.1838.00 1 M4 TC SCREW
48 60.2251.84 1 PLASTIC KNOB
49 14.3582.00 1 WASHER, D 30 MM
50 60.2254.31 1 M30 NUT
51 29.0096.24 1 PR 5 PL. HOUSING KIT
*KIT 8.704-548.0 - VB9.01+PR5 SPARE PARTS KIT,14X1 PCS
