Hotsy 1473P Dealer's Manual

49Hotsy 900/1400 Series Dealer Manual 9.803-324.0 - AW
Power Side
REF PART NO. QTY DESCRIPTION NOTES
1 8.920-783.0 1 FRAME, CONTROL PANEL, TOP
2 8.920-778.0 1 LID, ELECTRICAL BOX COVER
3 9.802-754.0 4 SCREW, 1/4” X 1" WHIZ LOC
4 9.802-103.0 1 BUSHING, 5/8” SNAP
5 8.707-058.0 1 STRAINER, 1/4” BRASS W/CHECK VALVE
6 6.390-126.0 3 CLAMP, HOSE,.46-,.54 ST
7 8.716-037.0 2 SWITCH, ROCKER 10A/250V-15A/125V, 24VLT
8 9.802-778.0 2 NUT, 5/16” WHIZ LOC
9 9.082-188.0 1 VALVE, METERING, 1/4” HOSE
10 8.751-055.0 14 RIVET, ALUM, 3/16” DIA
11 8.624-608.0 1 LAYNARD, 18.0 W/LOOP & EYE
12 9.800-016.0 1 LABLE, DISCONNECT POWER
13 8.922-407.0 2 BRACKET, DOOR LOCK 900-1400
14 8.706-547.0 3 GROMMET, RUBBER NOZZEL HOLDER
15 - 1 NOZZLE
SEE HOSE, GUN &
WAND PAGE
16 - 1 NOZZLE
SEE HOSE, GUN &
WAND PAGE
17 - 1 NOZZLE
SEE HOSE, GUN &
WAND PAGE
18 9.802-146.0 1 SWIVEL, 1/2” MP X 3/4” GHF W/STRAINER
19 9.800-020.0 1 LABEL, COLD WATER INLET
20 9.800-049.0 1 LABEL, MANUFACTURERS CLEANING SOLUTION
21 8.932-965.0 1 LABEL, WARNING, EXPOSED PULLEY
22 9.802-252.0 8 ft. HOSE, 1/4” X 1/2” BRAIDED VINYL
23 9.802-252.0 12" HOSE, 1/4” X 1/2” BRAIDED VINYL
24 8.921-204.0 1 LABEL, CONTROL PANEL
