51Hotsy 900/1400 Series Dealer Manual 9.803-324.0 - AW
Panel & Doors
REF PART NO. QTY DESCRIPTION NOTES
1 8.924-153.0 1 ASSY, PANEL, SIDE COIL
2 8.924-154.0 1 ASSY, PANEL, FRONT COIL
3 8.924-155.0 2 ASSY, PANEL, FRONT COIL
4 9.802-073.0 11.5 WEATHER STRIP, 1/8" X 1/2"
5 9.803-551.0 13 SCREW, 5/8" X 3/4", WHIZ LOC
6 8.920-773.0 1 BRACKET, CORNER EDGE, COIL END
7 8.920-772.0 1 BRACKET, CORNER, EDGE, PMP END
8 8.923-350.0 1 PANEL, REAR COVER
9 8.718-897.0 6 NUT, 5/16" SPEED
10 8.900-990.0 1 LABEL, INSTRUCTIONS, WARNINGS
11 8.932-965.0 1 LABEL, WARNING, EXPOSED PULLEY
12 8.751-055.0 42 RIVET, ALUMINUM 3/16" DIA. 062-.125 GRIP
13 9.706-548.0 1 GROMMET, 2-1/2" NOT SHOWN
14 8.920-777.0 1 LID, PUMP MOTOR, COVER
15 9.800-006.0 1 LABEL, HOT/CALIENTE
16 8.719-081.0 1 LATCH, SPRING, FLUSH HEAD
17 9.804-301.0 2 RIVET, 1/8" X 1/4"
