Hotsy 965B Series User Manual

24
Hotsy Gas Belt Drive Series Operator’s Manual 8.931-236.0 - BD
Wiring Diagram -1075BE CAL
12V BATTERY
SWITCH
PRESSURE
86
METER
HOUR
87
Y
RED 6GA
CONTROL BOX
BLK 12GA
RED 12GA
BLK 6GA
1
C
85
87a
30
A
B
C
RED
Y
Y
BLK
BRN
WHT
Y
ENGINE
+
-
R
E
D
ENGINE
REGULATOR
85
30
87a
86
87
RED
C
D
THERMOSTAT
BURNER MOTOR RELAY
BURNER SWITCH
IGNATOR/FUEL PUMP RELAY
30 AMP FUSE
