97-6574 • HOTSY 900-1400 GAS FIRED • REV. 10/05
25
PRESSURE WASHER
OPERATOR’S MANUAL
BURNER PARTS LIST
ITEM PART NO. DESCRIPTION QTY
1 95-0710200233 Angle, Gas Burner Bracket 1
2 Burner Ring, Please See Specifications Page
3 2-001681 Nipple, 3/4” x 9” Black 1
4 2-00293 Elbow, 3/4” Black, 90° 1
5 2-00151 Nipple, 3/4” x Close, Black 1
6 2-00163 Nipple, 3/4” x 2” Black 1
7 2-00166 Nipple, 3/4” x 3-1/2” Black Pipe 1
8 2-0037 Tee, 3/4” Black Pipe 1
9 2-00165 Nipple, 3/4” x 5” Black Pipe 1
10 2-00851 Cap, 3/4” Black Pipe 1
11 7-0150 Tubing, Aluminum, 600”/RL, 1/4” 10”
12 2-1116 Elbow, 1/4” Tube x 1/8” MPT, 90° 1
13 2-1072 Bushing, 1/4” x 1/8” Pipe 2
14 2-1117 Connector, 1/4” Tube x 1/8” MPT 1
15 2-3006 Valve, Ball, 1/4” Female x 1/4” Female 1
16 90-1010 Bolt, 5/16” x 1-3/4”, NC HH 1
17 90-19713 Screw, 5/16” x 3/4” Whiz Loc 2
18 90-4001 Washer, 5/16” Flat, SAE 6
19 90-20012 Nut, 5/16” Flange, Whiz Loc 3
20 7-700021 Valve, 3/4”, Natural Gas, 24V, 3.5 Honeywell 1
21 7-702371 Pilot, Ignitor, P, NG 1
22 95-07162025 Bracket, Pilot Light 1
23 90-1000 Bolt, 1/4” x 1/2” NC HH 2
24 90-4000 ▲ Washer, 1/4” Flat 2
25 90-199940 Screw, 10/32” x 1/4” HWH ROLOC, Z 2
26 90-10130 U-Bolt, 5/16” x 1”, Pipe 1
27 6-01353 Cable, Ignition, 60” 1
28 7-702320 LP, Conversion Kit (981SS, 991SS, 991SS-208, 994SS,
1411SS, 1421SS, 1421SS-208, 1424SS) 1
29 95-07104332 Bracket, Gas Train 1
30 7-701511 Connector, Ignition Module 1
▲ Not Shown
To Next Page
