97-6574 • HOTSY 900-1400 GAS FIRED • REV. 10/05
31
PRESSURE WASHER
OPERATOR’S MANUAL
CONTROL PANEL PARTS LIST
ITEM PART NO. DESCRIPTION QTY
1 7-701510 Module, Ignition, Electronic Honeywell 1
2 784227 Meter, Hour, 24V AC 1
3 4-05095 Knob, Thermostat 1
4 875985 Switch, Rocker, 10A/250V/125V, 24 Volt 1
(Auto Start/Stop Option) 2
5 875648 Relay, 24 Volt, DPST NO 2
6 6-0504004 Block, Terminal, 14 Pole 1
7 6-0507 Lug, Terminal Grounding, LAMA6-14-Q 1
8 90-1816 Screw, 8-32 x 1-1/4”, M PH PHD PL 1
9 90-200490 Nut, 8/32” Keps 4
10 90-29980 Screw, #8 x 1/2” Tek, Square Head, SS 6
11 921438 Valve, Metering, 1/4” Hose 1
12 2-9040 Clamp, Hose, UNI .46 - .54 ST 2
13 4-02090000 Hose, 1/4” x 1/2” Braided Vinyl 11 ft.
14 2-0103 Grommet, Rubber, Nozzle Holder 3
15 95-07104303 Stand-Off, E-Box 1
16 Contactor, Please See Specifications Page 38 1
17 Overload, Please See Specifications Page 38 1
18 Transformer, Please See Specifications Page 38 1
19 11-0510 Label, Hotsy, 900/1400 Control Panel 1
20 6-05152 Strain Relief, Straight, LQ Tite Small 2
(Options) 3
21 6-05181A Locknut, 1/2” Conduit 2
(Options) 3
22 6-051595 Strain Relief, Straight, LQ Tite Large 2
23 6-05181B Locknut, 3/4” 2
24 2-1905 Strainer, 1/4” Brass w/Check Valve 1
25 90-1815 Screw, 8-32 x 1/2”, M PH RDH PL 4
26 90-20012 Nut, 5/16” Flange, Whiz Loc 4
27 90-2001 Nut, 5/16” ESNA, NC 4
28 90-29980 Screw, #8 x 1/2” Tek, Square Head, SS 2
(Auto Start/Stop Option) 3
29 6-02403 Fuse, FNM-6.25 1
30 Fuse, Please See Specifications Page 38
31 95-07104328 Cover, Electrical Box 1
32 10-08021 Label, Disconnect Power Supply 1
33 4-050952 Thermostat w/1 meter Capillary 1
34 4-050951 Plate, Thermostat 1
35 90-1980 Screw, 4mm x 6mm, Panhead 2
36 2-017 Bushing, Star 1
37 2-0148 Plug, 7/8” Hole 2
(Options) 1
38 90-200490 Nut, 8/32” Keps 4
39 90-29980 Screw, #8 x 1/2” Tek, Square Head, SS 2
40 90-29981 Screw, #8 x 3/4” Tek, Zinc 2
41 2-01403 Bushing, 7/8” Snap 1
To Next Page
