Hoveround MPV5 - Hoveround MPV5 Component Diagram

12 Hoveround
®
MPV5 - Diagram D82008753M 10/13
Flip Up
Footplate
Hoveround
®
MPV5 - Diagram
Battery Cable
Connection
(if equipped)
Seat Belt
Seat
(Swivel Optional)
Brake Release
Levers
Adjustable
Arm Rest
Dual Motor Front
Wheel Drive
Joystick Controller
•
•
•
•
•
•
•
Anti Tip
Wheels
•
Batteries
•
•
•
