50 Chapter 7 D82008753M 10/13
Battery Removal/Replacement
(if equipped with separate removable batteries)
Removal
1. Remove each of the battery connectors by pinching the tab
on the connector at the junction box and gently pulling free
(See Figure 7G, Page 49).
2. Carefully lift the battery and case clear of the base.
Replacement
1. Either battery can fit onto either side of the base.
2. Place the battery into the vehicle deck recess which is located
on the base under the seat with the cable facing rearward.
3. Insert the connector into the appropriate receptacle of the
junction box. The left battery connects to the receptacle on
the left side, right battery connects to the receptacle on the
right side.
4. Lock the battery connector plug to the receptacle by pushing
until a click is heard. Gently pull on the connector to ensure
it is fully locked in place.
