Press either seat symbol button to activate the PSL mode
(see Figure 5A below). When the indicator light is lit, move the
joystick forward to raise the seat, back to lower. The MPV5 will
not drive while seat is raised and light is on. When seat is fully
down, press either button to restore drive mode. Your power
wheelchair contains a lock-out feature that prevents driving
when the seat is in the raised position.
D82008753M 10/13 Chapter 5 41
Indicator Light
Seat Symbol Buttons
Figure 5A
Optional Reclining Back Seat
Driving with the seatback reclined makes it difficult to see where
you are going and increases the chance of serious injury or
death from collision and tip-over. Do not attempt to drive this
vehicle with seatback reclined.
The optional reclining seat will permit the seatback to recline
approximately 45 degrees.
