What to do if my Hoymiles Inverter has a firmware error?
Check if the Hoymiles Inverter firmware is correct and has been upgraded. Then, check the communication between the DTU and the Hoymiles monitoring system, and between the DTU and the microinverter. Try again after checking the communication. If the fault persists, further assistance may be needed.
What to do if my Hoymiles HMS-1600-4T Inverter shows grid overvoltage?
If the Hoymiles Inverter alarm occurs occasionally, the grid voltage may be temporarily abnormal, and the microinverter should automatically recover once the grid voltage returns to normal. If the alarm occurs frequently, verify that the grid voltage is within the acceptable range. If it's not, contact your local power operator or, with their consent, adjust the grid overvoltage protection limit in the grid profile via the Hoymiles monitoring system.
What to do if my Hoymiles Inverter shows 10 min value grid overvoltage?
If the Hoymiles Inverter alarm occurs occasionally, the grid voltage may be temporarily abnormal, and the microinverter should automatically recover once the grid voltage returns to normal. If the alarm occurs frequently, verify that the grid voltage is within the acceptable range. If it's not, contact your local power operator or adjust the grid overvoltage protection limit via Hoymiles monitoring system with their consent.
Why is my Hoymiles HMS-1600-4T Inverter offline?
First, ensure the Hoymiles microinverter is working correctly by checking if the DC voltage is within the normal range and confirming the LED indicator status. Next, verify that the serial number (SN) on the microinverter label matches the one on the monitoring platform. Then, check the communication status between the DTU and the Hoymiles monitoring system, as well as between the DTU and the microinverter. If the communication is poor, try to improve it. If the alarm persists and cannot be resolved, further assistance may be needed.
How to troubleshoot over temperature protection on a Hoymiles HMS-1600-4T Inverter?
Check the ventilation and ambient temperature at the Hoymiles microinverter's installation location. If ventilation is poor or the ambient temperature exceeds the limit, improve ventilation and heat dissipation. If the problem persists with adequate ventilation and temperature, further assistance may be needed.
What to do if my Hoymiles Inverter was shut down by remote control?
Check the status of zero export management and whether the Hoymiles microinverters were manually shut down. If the alarm still persists, further assistance may be needed.
What to do if there is a grid configuration parameter error on my Hoymiles Inverter?
Check if the grid configuration parameter is correct and upgrade it. If the fault still exists, further assistance may be needed.
General| Model | HMS-1600-4T |
|---|---|
| Category | Inverter |
| Input Voltage Range | 16-60V |
| Max DC Input Voltage | 65V |
| Output Power | 1600W |
| Output Voltage | 230V |
| Efficiency | 96.5% |
| Startup Voltage | 22V |
| Rated Output Power | 1600W |
| Maximum Output Power | 1600W |
| Power Factor | >0.99 |
| Total Harmonic Distortion (THD) | <3% |
| Efficiency CEC | 96% |
| Enclosure Rating | IP67 |
| Number of MPPT Trackers | 4 |
| Maximum AC Output Power | 1600W |
| Peak Efficiency | 96.7% |
| Cooling Method | Natural Convection |
| Max Input Current | 14A per MPPT |
| Maximum Input Current | 14A per MPPT |
| Nominal Output Frequency/Range | 50/60Hz |
| Ambient Temperature Range | -40°C to +65°C |
| Operating Temperature Range | -40 ~ +65℃ |
| Recommended PV Module Power | 320-540W |
Outlines crucial safety precautions for installation, operation, and maintenance by qualified personnel.
Provides guidelines and illustrates methods for connecting PV modules to the microinverter.
Provides step-by-step instructions for planning and installing the microinverter onto the mounting rail.
Instructions for connecting the microinverter's AC sub-connector and the AC end cable.
Steps for mounting PV modules and connecting their DC cables to the microinverter.
Instructions for turning on the AC breakers to energize the installed system.
A list of alarm codes, statuses, and suggested handling actions for microinverter issues.
Continues troubleshooting for grid voltage, frequency, and input voltage issues.
Details troubleshooting for input voltage, no input, abnormal wiring, and device failure alarms.
Explains the meaning of LED indicator lights during start-up, operation, and other status conditions.
Provides a step-by-step guide for on-site inspection of malfunctioning microinverters.
Details procedures for removing, replacing a microinverter, and updating monitoring platform status.
Compares technical specs (input/output, efficiency) across different microinverter models.
Illustrates the wiring diagram for a 120VAC/240VAC split-phase system, showing PV module and grid connections.
Shows the wiring diagram for a 120VAC/208VAC three-phase system with PV modules and grid connections.
