Three-phase Microinverter HMT-1600/1800/2000-4T
4.3 Installation Tools
Besides tools recommended below, other auxiliary tools can also be used on site.
Screwdriver Multimeter
Socket Wrench or Allen wrench Marker pen
Diagonal pliers Steel tap
Wire cutters Cable tie
Wire stripper Torque and adjustable wrench
Utility knife
Safety glove Dust masks
Protective goggles Safety shoes
HMT-1600-4T HMT-1800-4T HMT-2000-4T
Maximum over current
protection device (OCPD)
Maximum number
per 12 AWG branch
8@220 V
8@230 V
9@240 V
7@220 V
7@230 V
8@240 V
6@220 V
6@230 V
7@240 V
20 A
Maximum number
per 10 AWG branch
13@220 V
13@230 V
14@240 V
11@220 V
12@230 V
12@240 V
11@220 V
11@230 V
11@240 V
32 A
4.4 AC Branch Circuit Capacity
Hoymiles HMT-1600-4T/HMT-1800-4T/HMT-2000-4T can be used with 12AWG or 10AWG AC Trunk Cable and
the AC Trunk Connector which are provided by Hoymiles. The number of microinverters on each 12AWG or
10AWG AC branch shall not exceed the limit as shown below.
Note:
• The number of microinverters that can be connected to each AC branch is determined by the ampacity (also
known as current-carrying capacity) of the cable.
• 1-in-1, 2-in-1 and 4-in-1 microinverters can be connected to the same AC branch, as long as the total current
does not exceed the ampacity specied in local regulations.
