Speakers
Description Spare part number
Speaker Kit (includes left and right speakers and cables) 788555-001
Before removing the speakers, follow these steps:
1. Turn o the computer. If you are unsure whether the computer is o or in Hibernation, turn
the computer on, and then shut it down through the operating system.
2. Disconnect the power from the computer by unplugging the power cord from the computer.
3. Disconnect all external devices from the computer.
4. Remove the keyboard/top cover (see Keyboard/top cover on page 24).
5. Remove the system board (see System board on page 39).
Remove the speakers:
1. Release the speaker cables from the routing clips (1) and channels built into the base enclosure.
2. Remove the speakers (2).
Reverse this procedure to install the speakers.
42 Chapter 5 Removal and replacement procedures
