Bottom cover
Table 5-1 Bottom cover descriptions and part numbers
Description Spare part number
Bottom cover, natural silver L64894-001
Bottom cover, pale gold L64895-001
Bottom cover, snowake white L64896-001
Rubber feet, gold L66226-001
Rubber feet, silver L65866-001
Before removing the bottom cover, follow this step:
▲ Prepare the computer for disassembly (Preparation for disassembly on page 26).
Remove the bottom cover:
1. Peel the two rubber feet o the bottom cover.
2. Remove the ve Phillips M2.0 × 6.0 screws (1) from the bottom cover.
3. Remove the two Phillips M2.5 × 6.0 screws (2) from the bottom cover.
Component replacement procedures 27
