Solid-state drive
Table 5-4 Solid-state drive descriptions and part numbers
Description Spare part number
512 GB, PCIe, Gen 3 × 4, TLC L72365-001
512 GB, PCIe, value L61960-001
256 GB, PCIe, value L61959-001
128 GB, SATA-3, TLC L61958-001
64 GB, eMMC L61957-001
Before removing the solid-state drive, follow these steps:
1. Prepare the computer for disassembly (Preparation for disassembly on page 26).
2. Remove the bottom cover (see Bottom cover on page 27).
3. Remove the battery (see Battery on page 29).
Remove the solid-state drive:
▲ Remove the Phillips M2.0 × 2.5 screw (1), and then pull the drive from the socket (2).
Reverse this procedure to install the solid-state drive.
32 Chapter 5 Removal and replacement procedures for authorized service provider parts
