c. Remove the webcam/microphone module (2). (The module is attached to the display enclosure
with double-sided tape.)
3. To remove the display panel:
a. Remove the six Phillips PM2.5×4.0 screws (1) that secure the display panel to the enclosure, and
then rotate the display panel (2) onto the computer.
NOTE: In this procedure, the display will NOT be connected to the computer, as shown in the
following image.
Component replacement procedures 65
