HP 14 User Manual

Hard drive
NOTE: The hard drive spare part kit does not include the hard drive cable or bracket.
Description Spare part number
1-GB, 5400-rpm, 2.5-in 676521-005
750-GB, 5400-rpm, 2.5-in 634250-005
500-GB, 5400-rpm, 7.0-mm (for use only in HP 14 and Compaq 14 models) 683802-005
500-GB, 5400-rpm, 2.5-in (for use only in HP 240 models) 669299-005
320-GB, 5400-rpm, 2.5-in (for use only in HP 240 models) 622643-005
Hard drive bracket 747117-001
Before removing the hard drive, follow these steps:
1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet and
then unplugging the AC adapter from the computer.
4. Remove the battery (see
Battery on page 43), and then remove the following components:
●
Service door (see
Service door on page 49)
●
Top cover (see
Top cover/keyboard on page 55)
To remove the hard drive:
1. Lift the USB board cable to disengage the adhesive that secures it to the hard drive (1)
2. Remove the three Phillips PM2.5×4.5 screws (2) that secure the hard drive to the computer.
3. Lift the hard drive (3) to gain access to the connector.
70 Chapter 4 Removal and replacement procedures
