b. Flex the inside of the top edge (1), the left and right edges (2), and the bottom edge (3) of the
display bezel until the bezel disengages from the display enclosure.
c. Remove the display bezel (4).
NOTE: In this procedure, the display will NOT be connected to the computer, as shown in the
following image.
2. To remove the webcam/microphone module:
a. Position the display assembly with the top edge toward you.
b. Disconnect the cable (1) from the module.
64 Chapter 4 Removal and replacement procedures
