HP 15z-cw100 User Manual

b. Rotate the display panel over and place it next to the display enclosure (3).
NOTE: Pull the tape out slowly and evenly to prevent it from breaking prematurely.
Display adhesive is available in the Adhesive Kit as spare part number M26981-001.
Display panels are available as the following spare part numbers:
M09819-001: Antiglare, UWVA, FHD
M09820-001: Antiglare, SVA, FHD
M09821-001: BrightView, SVA, HD
M09822-001: BrightView, UWVA, FHD, Touch-On Panel (TOP)
M09824-001: BrightView, UWVA, HD
M15993-001: BrightView, SVA, HD, Touch-On Panel (TOP)
c. Release the adhesive support strip (1) that secures the display panel cable connector to the display
panel.
d. Disconnect the display panel cable (2) from the display panel, and then remove the display panel
(3).
Component replacement procedures 47

HP 15z-cw100 Specifications

General

Storage	256GB PCIe NVMe M.2 SSD
Operating System	Windows 10 Home
Battery	3-cell, 41 Wh Li-ion
Audio	Dual speakers
Color	Natural Silver
RAM	8GB DDR4-2400 SDRAM
Weight	4.08 lb
Wireless	Realtek RTL8821CE 802.11b/g/n/ac (1x1) and Bluetooth 4.2
Ports	1 HDMI 1.4b; 1 RJ-45; 1 headphone/microphone combo
Dimensions	14.11 x 9.53 x 0. in
Graphics	AMD Radeon Vega 8 Graphics
