Item Component Spare part number
●
Intel Core i3-7020U processor with 2 GB of AMD Radeon 520 graphics memory L22744-xx1
●
Intel Pentium N5000 processor with 2 GB of AMD Radeon 520 graphics memory L22745-xx1
For use in models with UMA graphics memory:
●
Intel Core i7-8550U processor L22735-xx1
●
Intel Core i5-8265U processor L32627-xx1
●
Intel Core i5-8250U processor L22736-xx1
●
Intel Core i3-8130U processor L22737-xx1
●
Intel Core i7-7500U processor L22738-xx1
●
Intel Core i5-7200U processor L40643-xx1
●
Intel Core i3-7020U processor L22739-xx1
●
Intel Pentium N5000 processor L22740-xx1
●
Intel Celeron N4000 processor L22741-xx1
(9) Optical drive board L22540-001
(10) USB board L22538-001
(11) Solid-state drive
NOTE: For spare part information, see Mass storage devices on page 23.
(12) Memory modules (2400 MHz DDR4)
8 GB 862398-855
4 GB 862397-855
(13) WLAN module
Intel Dual Band Wireless-AC 9461 802.11 AC 1×1 WiFi + BT5 Combo Adapter (non-vPro) (MU-
MIMO supported)
L25889-005
Realtek RTL8822BE 802.11 ac 2x2 WiFi + Bluetooth 4.2 Combo Adapter (MU-MIMO supported) 924813-855
Realtek RTL8821CE 802.11 ac 1x1 WiFi + Bluetooth 4.2 Combo Adapter (MU-MIMO supported) L17365-005
Realtek RTL8723DE 802.11 bgn 1x1 WiFi + Bluetooth 4.2 Combo Adapter L21480-005
(14) Fan L22529-001
Fan insert (for use in models without a fan; not illustrated) L29669-001
Heat sink
(15) For use in models with Intel Core processors and discrete graphics L22531-001
(16) For use in models with Intel Core processors and integrated UMA graphics L22530-001
(17) For use in fanless models with Intel Pentium and Celeron processors L22532-001
(18) Battery (3-cell, 41 WHr) L11119-855
(19) Hard drive
NOTE: For spare part information, see Mass storage devices on page 23.
(20) Solid-state drive bracket L22535-001
18 Chapter 3 Illustrated parts catalog
