HP 17 User Manual

Optane memory module
IMPORTANT: The M.2 connector that supports the Optane memory module can also support a solid-state
drive. You cannot simultaneously install both an Optane memory module and a solid-state drive in the
computer.
Description Spare part number
Optane memory module, 16 GB Lxxxxx-001
Before removing the Optane memory module, follow these steps:
1. Shut down the computer.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by rst unplugging the power cord from the AC outlet and then
unplugging the AC adapter from the computer.
4. Remove the optical drive (see Optical drive on page 32).
5. Remove the bottom cover (see Bottom cover on page 36).
6. Remove the battery (see Battery on page 38).
Remove the Optane memory module:
▲
Remove the Phillips M2.0×3.0 screw (1), and then pull the solid-state drive module from the socket (2).
Reverse this procedure to install the Optane memory module.
44 Chapter 6 Removal and replacement procedures for Authorized Service Provider parts

HP 17 Specifications

General

Category	Laptop
Screen Size	17.3 inch
CPU	Intel Core i3/i5/i7 or AMD Ryzen 3/5/7
Operating System	Windows 11 Home
Storage	1TB SSD
Processor	Intel Core i3/i5/i7 or AMD Ryzen 3/5/7
Display	HD+ or FHD
Graphics	AMD Radeon Graphics
Battery	3-cell Li-ion
Ports	USB Type-A, USB Type-C, HDMI, headphone/microphone combo jack
Wireless	Wi-Fi 5 (802.11ac) or Wi-Fi 6 (802.11ax), Bluetooth 5.0 or later
