Item Component Spare part number
(2) Display bezel
Non-touch models L22517-001
Touch models L22518-001
(3) Display panel
HD, BrightView, SVA, non-touch L22561-001
HD, anti glare, SVA, non-touch L22562-001
HD, BrightView, SVA, touch-on panel (TOP) L22563-001
FHD, anti glare, UWVA, non-touch L22564-001
(4) Hinge Kit (includes left and right hinges) L22536-001
(5) Touch control board L22541-001
(6) Camera module
HD camera L22587-001
VGA camera L22588-001
Display cable
(7) Non-touch, HD L22519-001
Non-touch, FHD (not illustrated) L22520-001
(8) Touch, HD (not illustrated) L22521-001
(9) WLAN antenna cable (included in Antenna Kit)
Single antenna L22498-001
Dual antennas L22497-001
(10) Back cover
Jet black L22506-001
Natural silver L22499-001
Pale gold L22500-001
Scarlet red L22501-001
Twilight blue L22504-001
Smoke gray L22503-001
Snow white L22507-001
Serenity mint L22502-001
Twilight blue L22504-001
Maroon burgundy L22505-001
Tranquil pink L25489-001
Iridescent pale rose gold L25490-001
Iridescent ceramic white L25491-001
22 Chapter 3 Illustrated parts catalog
