5–20 Maintenance and Service Guide
Removal and Replacement Procedures
1. Prepare the computer for disassembly (Section 5.3).
2. Loosen the Phillips PM2.0×5.0 screw 1 that secures the
Mini Card compartment cover to the computer.
3. Lift the right edge of the Mini Card compartment cover 2,
and then swing it to the left.
4. Remove the Mini Card compartment cover.
✎
The Mini Card compartment cover is included in the Plastics
Kit, spare part number 417073-001.
Removing the Mini Card Compartment Cover
