Product Description
Maintenance and Service Guide 1–19
The external components on the bottom of the computer are
shown below and described in Table 1-9.
Bottom Components
Table 1-9
Bottom Components
Item Component Function
1 Battery bay Holds the battery
2 Battery release latch Releases the battery from the battery
bay.
3 Optical drive Reads an optical disc.
4 Hard drive bay Holds the hard drive.
