5–28 Maintenance and Service Guide
Removal and Replacement Procedures
5.11 Switch Cover
1. Prepare the computer for disassembly (Section 5.3).
2. Remove the keyboard (Section 5.10).
3. Close the computer.
4. Turn the computer upside down with the front panel
toward you.
5. Remove the three Phillips PM2.5×9.0 screws 1 and the silver
Phillips PM2.5×5.0 screw 2 that secure the switch cover to
the computer.
Removing the Switch Cover Screws
Switch Cover Spare Part Number Information
For use with full-featured computer models
For use with defeatured computer models
417079-001
417080-001
